High Wear Resistant Bar Kelly Interlocking In Drilling Engineering

Name: High Wear Resistant Bar Kelly Interlocking In Drilling Engineering
Brand: JTHL
Price: 10000 USD

Brand Name : JTHL

Model Number : OD368

Certification : ISO

Place of Origin : China

MOQ : 1 set

Price : USD 10000-USD 20000

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets/ month

Delivery Time : 5-8 work days

Packaging Details : Packaged With Steel Pallet and Aluminium Film

Usage : Rotary Piling Rig Attachment

Product Name : Construction Drilling Tools

Type : Interlocking

Drilling Depth : 30-140m

Advange : Factory

Contact Now

Kelly bar is based on domestic rig configuration and condition demand, combined with the home and abroad advanced manufacture technology, supporting domestic and foreign rotary piling rig.

No.	Diammeter of The First Section	Sections			Key Pressure Type	Length of per section(m)	Drill depth	Torque(KN.M)
1	¢299	3			Interlocking	9-12	24-45	100 -120
2	¢342	3	4		Interlocking	9 - 12	24-45	100 -120
3	¢355	3	4		Interlocking	9 - 14	24 - 56	100-120
4	¢368	3	4		Interlocking	9 - 14	24 - 56	150-180
5	¢377	3	4		Interlocking	9 - 14	24 - 56	150-180
6	¢394	3	4		Interlocking	9 - 15	24 - 58	180-200
7	¢406	3	4		Interlocking	9 - 15	24 - 58	180-200
8	¢419	3	4		Interlocking	9 - 15	24 - 58	200-230
9	¢440(445)	3	4		Interlocking	9 - 15	24 – 58	220-260
10	¢470 (482)	3	4		Interlocking	9 - 16	24 – 60	220-260
11	¢508	3	4		Interlocking	9 – 18	24 – 68	260-360
12	¢530 (540)	3	4	5	Interlocking	9 – 20	32 – 92	320-400
13	¢580(575)	3	4	5	Interlocking	9 – 20	32 – 92	360-420
14	¢630	3	4	5	Interlocking	9 - 22	32 - 102	400-500

High Wear Resistant Bar Kelly Interlocking In Drilling Engineering
